Stationary Electric Hydraulic Scissor Lift Tables Max Height 4140mm 400kg

Brand Name : JS

Model Number : HF400

Certification : CE,SGS

Place of Origin : China

MOQ : 10 set

Price : Negotiation

Payment Terms : T/T, L/C, Western Union

Supply Ability : 2000 sets per month

Packaging Details : Carton package and Pallet package

Problem Name : Hydraulic Stationary scissor Lift Table

Material : High strength steel

Core Components : Pressure vessel

Keywords : Electric Scissor Lift Tables

After-sales service provided : Video Technical Support,Free Spare Parts During Waranty

Weight : 600kg

Table Size : 100 X170 cm

Min. lifting height : 60 cm

Max. lifting height : 4.14 m

Elevating Time : 30-40 s

Rated loading capacity : 0.4 ton

Feature : Easy Operation Safety Convenience

Application : Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company

Contact Now

Max Height 4140mm Rated Lifting Capacity 400kg Stationary Electric Multi Scissor Lift Tables

Fixed multi scissor electric lift table

The Multi Heavy Duty scissor lift table provides excellent vertical lift range, using Electric hydraulic pistion to raise the platform to heights between 850mm and 4200mm. The operator simply increase the working height of the table, thereby raising the double scissor lift. Capable of handling loads up to 2000kg, the scissor lift tables is easy to use and easy to move - ideal for use in engineering, storage and manufacturing environments.

Limit components adjust the desire height by controller. Industrial design with high-quality components, the hydraulic lift table comes standard with two brake casters that prevent the table from moving when unloaded. In addition, the heavy-duty hydraulic pump mechanism is equipped with a slow-down valve to ensure smooth movement during the lifting process.

Model	Unit	HF400
Rated Lifting Capacity	Kg	400
Min Height	mm	600
Max Height	mm	4140
Platform Size	mm	1000X1700
Base Size	mm	1000X1600
Elevating Time	s	30~40
Fall Time	s	30~40
Hydraulic Power		AC380V, 2.2KW
N.W.	kg	600

heavy duty scissor lift tables,double scissor lift,stationary scissor lift,1ton scissor lift tables, 1000kg hydraulic lifter, lift tables

Max height 4140mm mulit scissor lift tables Electric power assist Electric fixed scissors lifting platform Three-phase support, power in watts. Ideal technical design to provide multi - shear lifting support

Oil box Superior Oil for hydraulic system to keep pistion perfect performance. elect

Standard thickness steel with Perfect Heavy-duty torsional steel frame heavy duty cylinder; Heavy Steel Legs The stationary five Scissors Lift Tables with double pistion and Standard thickness steel make this Vertical lifting in powerful condition.or Lift tables

Standard hand control This stationary scissor lift tables with standard hand control, which is easy to raise the ideal height what you want by Up and Down button. Standard hand control is with a safety wire.It is adjustable wire in length.

Assemble and workshop
